EHS-1 Holographic Sight

(No reviews yet) Write a Review
$599.00

The EHS-1 Enhanced Holographic Sight is a rugged, precision-engineered optic offering rapid target acquisition, extreme durability, and advanced features for tactical and competitive shooting in any environment.



What's included:
- EHS-1 Holographic Sight

- Quick Reference Guide

- One CR123 Battery


PATENT PENDING

SKU:
EHS1
Availability:
Usually ships within 24 hours.

Expected release date is Mar 31st 2025

Adding to bag… The item has been added

Description

The EHS-1 Enhanced Holographic Sight from Dynamic Optronic Technologies is a precision-engineered solution for professionals and enthusiasts seeking unmatched accuracy and reliability. Designed with a 1 MOA center dot and a 65 MOA outer ring, it facilitates rapid target acquisition while ensuring precision for both tactical applications and competitive shooting.

Constructed from durable 7075 aluminum with an anodized finish, the EHS-1 is built to withstand harsh environments. Its anti-reflective coated lenses deliver a clear field of view, and it offers unlimited eye relief for maximum adaptability. Powered by a single CR123A battery, it provides an average of 1,000 hours of continuous operation at medium brightness. Additional features include low battery warnings, Dynamic Wake motion activation, and an auto shut-off function to conserve power.

The EHS-1 is IP68-rated for water and dust resistance and can operate in extreme temperatures ranging from -40°F to 131°F, ensuring dependable performance in diverse conditions. Designed for use with MIL-STD-1913 (Picatinny) rails, it integrates seamlessly with a variety of platforms. Adjustable windage and elevation settings, precise to 0.5 MOA per click, ensure accuracy at a range of distances.

With a focus on ease of use, durability, and performance, the EHS-1 stands as a reliable tool for demanding environments.

Downloads


Technical Specification

Optical

Magnification: 1x

Eye Relief: Unlimited

Window Size: 1.2in x 0.8in (30.5mm x 20.5mm)

Reticle: 1 MOA Center Dot, 65 MOA


Wavelength: 650nm

Lens Coating: Anti-refection coating, all surfaces

Electrical

Battery: CR123A

Continuous Working Hours:

≥ 1000 hours (medium brightness)

Low Battery Warning:

Reticle begins flashing in-window

Mechanical

Material: 7075 Aluminum

Surface Finish: Anodize

Adjustment Range:

± 40 MOA windage/elevation

Adjustment Increment: 0.5 MOA


Size: 2.13in x 2.09in x 3.03in
(54mm x 53mm x 77mm)

Centerline: 2.26in (57mm)

Weight: 260g (without battery)

Mount: MIL-STD 1913 rail / Picatinny rail

Environmental

Working Temperature:

-40°F to 131°F (-40°C to 55°C)

Storage Temperature:

-40°F to 131°F (-40°C to 55°C)

Waterproofing: IP68
